Salami CO FRICTION Kit

Ask A Question

Description & Features

The Salami CO FRICTION Kit is designed for VD6A Series Working Sections. These cast-iron bodies can accommodate up to 8 work sections, offering parallel, series, and tandem circuits with load check valve protection on each section.

Spools are hardened steel and nickel-plated for durability and long service life, and are also interchangeable. Available controls include manual, cable, electric, electro-hydraulic, proportional hydraulic, pneumatic, and electro-pneumatic options.

This Salami product has a 12 GPM flow rating and can withstand a maximum operating pressure of 5100 PSI on ports P, A, and B.

SKU: R23400322

Supplier Part Number (MPN): R23400322

Alternate Part Numbers: C1MU20

Specifications

Brand
Salami
Key
3
Sg Fluid Viscosity
12 cSt to 75 cSt Optimal, 10 cSt Minimum, 400 cSt Maximum
Sg Internal Leakage
1.1 to 1.52 cu-in/min at 2285 psi
Sg Maximum Back Pressure
363 psi on Outlet Port T
Sg Recommended Filtration
19/16 um
Suitable For Use With
VD6A C0 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 C0 Series Monoblock Directional Valves

Similar Products

Model Number Flow Rate Suitable For Use With Price Action
Spool positioning with microswitch, conversion from (CE) to (CM), IP65.

R20288881 VD6A Series Working Section

VD6A and VD8A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 and VDM8 Series Monoblock Directional Valves

Salami LEVER STICK KNOB And KNOB Kit

420192000 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 Series Monoblock Directional Valves

Working section (P12A-PRA.PRB-NLA-F2), parallel circuit, 4-way 4-pos. A & B closed in neutral, spring centered to neutral, float detent (3), standard protected lever control (4), aux. valve plugs (5). SAE-8 work ports. Does NOT include M8 threaded handle.

S23480270 VD6A Series Working Section

Port relief (VA), adjustable 1900 PSI to 2970 PSI

R25000631 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Spool seal retainer plate (SL)

R23400050 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 Series Monoblock Directional Valves

Working section (T01A-PRA.PRB-NLA-C2), tandem circuit, 4-way 3-pos. A & B closed in neutral,spring centered to neutral (3), standard protected lever control (4), aux. valve plugs (5). SAE-8 work ports. Does NOT include M8 threaded handle.

S23480580 VD6A Series Working Section

Working section (P02A-PRA.PRB-ESA-E7B), parallel circuit, 4-way 3-pos. A&B to tank in neutral, spring centered direct-electric ON-OFF control 12VDC (3), safety lever (4), aux. valve plugs (5). SAE-8 work ports.

S23480761 VD6A Series Working Section

Electric kit with safety lever, 12 VDC direct acting, 3-position (02A-ESA-E7)

R23101053 VD6A Series Working Section

VDM6 Series 12 VDC Direct-Acting 3-Position Motor Spool Monoblock Directional Valves

Salami VDM6/VD6A R9 DETENT Kit

R23400321 VD6A Series Working Section

VD6A R9 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 R9 Series Monoblock Directional Valves

Port relief (VA), adjustable 1030 PSI to 1885 PSI

R25000621 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Work section side seal kit.

R23400200 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Port relief (VA), adjustable 2980 PSI to 4785 PSI

R25000641 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL

S23480550 VD6A Series Working Section

Spool positioning for micro switch (CE). Pre-arrangement for electrical device.

R23402000 VD6A Series Working Section

VDM6 Series Monoblock Directional Valves

Salami VDM6/VD6 E9 45W 12V

796332555 VD6A Series Working Section

VD6A E9 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 E9 Series Monoblock Directional Valves

Port valve plug (PRA-B).

R23400500 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Cable control actuator (TC)

R360T0600 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Salami LEVER STICK POSITIONING Kit. PR

R23400060 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 Series Monoblock Directional Valves

SALAMI R5 DETENT KIT

R23400250 VD6A Series Working Section

VD6A R5 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 R5 Series Monoblock Directional Valves

Cross lever for 2 spools

R23400033 VD6A Series Working Section

VD6A Series 2-Spool L1 to L2 Fulcrum on Up-Stream Spool Hydraulic Proportional (IP) Control Directional Valves

Electric kit safety lever, 12 VDC direct acting, 3-position cylinder spool (01A-ESA-E7)

R23101031 VD6A Series Working Section

VDM6 Series 12 VDC Direct-Acting 3-Position Cylinder Spool Monoblock Directional Valves

Cross lever for 2 spools

R23400036 VD6A Series Working Section

VD6A Series 2-Spool Double-Acting Spool and Float Spool Hydraulic Proportional (IP) Control Directional Valves

Detent (R4) on position 1, spring return in neutral.

R23400280 VD6A Series Working Section

VD6A R4 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 R4 Series Monoblock Directional Valves

Working section (S01A-PRA.PRB-NLA-C2), series circuit, 4-way 3-pos. A & B closed in neutral,spring centered to neutral (3), standard protected lever control (4), aux. valve plugs (5). SAE-8 work ports. Does NOT include M8 threaded handle.

S23480480 VD6A Series Working Section

Hydraulic proportional control kit (IP).

R23100080 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 Series Monoblock Directional Valves

SALAMI VD6A-P01A-PRA.PRB-ESA-E7B/S ELECT

S23480542 VD6A Series Working Section

SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL

S23480070 VD6A Series Working Section

Salami VDM6/VD6 02A M Spool

323411302 VD6A Series Working Section

VD6A 02A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 02A Series Monoblock Directional Valves

Salami R2 DETENT Kit

R23400320 VD6A Series Working Section

VD6A R2 Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 R2 Series Monoblock Directional Valves

Pneumatic proportional control kit (PP).

R23400100 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves, VDM6 Series Monoblock Directional Valves

Anti-cavitation port valve (VR).

R23400550 VD6A Series Working Section

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

9. Relief Valve Cartridge (725 PSI) for Internal By-Pass Relief Valve Option (2 ea.)

R25000611 Internal Relief Valve Cartridge

VD6A Series Hydraulic Proportional (IP) Control Directional Valves

Product Questions & Answers (4)

Question by: Brent J on May 17, 2025, 9:47 PM
Just want to make sure, this friction kit is for the Salami VD6A series valves, right?
Answer by: Customer Support on May 19, 2025, 6:22 AM
That's correct. This friction kit is specifically listed as compatible with the Salami VD6A series.
Question by: Earl R on Dec 9, 2025, 4:48 PM
got a VD6A valve stack, is this the right friction kit for it or am i lookin at the wrong thing
Answer by: Customer Support on Dec 11, 2025, 6:39 AM
The key detail is the model label tied to this kit. It’s listed for the Salami VD6A Series, with catalog number C1MU20 and supplier part number R23400322.
Question by: Roy E on Oct 16, 2025, 2:19 PM
what's the fluid temperature range on this kit, and does it hold up alright with standard seals?
Answer by: Customer Support on Oct 18, 2025, 1:24 PM
With the NBR seals that come standard, fluid temps anywhere from -4°F up to 185°F are within spec. That covers most working conditions you'd run into on typical hydraulic equipment. If your application runs hotter or colder than that range on a regular basis, you'd want to look at a different seal configuration, but for everyday mineral oil systems those limits are pretty generous.
Question by: Bonnie H on Feb 11, 2026, 3:58 PM
Can this friction kit handle hot weather, like if it's sitting in the sun all day?
Answer by: Customer Support on Feb 12, 2026, 8:25 PM
The Salami CO friction kit is rated to handle ambient temperatures from -22°F up to 140°F, and fluid temperatures up to 185°F with standard NBR seals. So, it should be fine in most sunny conditions.
