SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL

Description & Features

The Salami VD6A Series Working Section is engineered for robust hydraulic applications, offering a versatile solution with parallel, series, and tandem circuits. Designed with cast-iron bodies, it supports up to 8 work sections, providing flexibility for various industrial needs. This working section is equipped with hardened steel and nickel-plated spools, ensuring durability and longevity under rigorous conditions. Capable of handling a maximum operating pressure of 5100 PSI and a flow rating of 12 GPM, it is suitable for demanding hydraulic systems.

With operating temperature ranges from -22°F to 140°F and fluid temperature compatibility from -4°F to 185°F, the VD6A Series is adaptable to diverse environments. It features auxiliary valves for ports A and B, and offers multiple control options including manual, electric, and pneumatic, enhancing its application scope. The inclusion of a load check valve in each section adds an extra layer of protection to your hydraulic setup.

SKU: S23480550

Supplier Part Number (MPN): S23480550

Alternate Part Numbers: C1MV23

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key (1)	Supplier Part Number S23480550	Alternate Part Numbers Alternate Part Number C1MV23	Product Weight 1.90 lbs

Similar Products

Model Number	Key	Product Description
323411302 VD6A Series Working Section	(2)	SALAMI VDM6/VD6 02A M SPOOL.
R23400322 VD6A Series Working Section	(3)	SALAMI CO FRICTION KIT.
420192000 VD6A Series Working Section	A side actuator	SALAMI LEVER STICK KNOB AND KNOB KIT.
796332555 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6 E9 45W 12V.
R23400060 VD6A Series Working Section	(4)	SALAMI LEVER STICK POSITIONING KIT. PR.
R23400210 VD6A Series Working Section	Spool	SALAMI VDM6/VD6 SPOOL SEAL KIT.
R23400320 VD6A Series Working Section	(3)	SALAMI R2 DETENT KIT.
R23400321 VD6A Series Working Section	B side actuator	SALAMI VDM6/VD6A R9 DETENT KIT.
S23480070 VD6A Series Working Section	(1)	SALAMI VD6A-P01A-PRA.PRB-NLA-C2/S PARALL.
S23480550 VD6A Series Working Section	(1)	SALAMI VD6A-P02A-PRA.PRB-NLA-C2/S PARALL.

Product Questions & Answers (2)

Question by: Patty H on Nov 14, 2025, 10:40 AM

got a setup that sees about 12 gpm. is this VD6A working section gonna be the choke point or will it keep up

Answer by: Customer Support on Nov 15, 2025, 3:54 PM

At 12 GPM, it matches the section’s published flow rating, so it is sized to run at that flow without you automatically outgrowing it. Pressure capability is up to 5100 PSI on ports P, A, and B, and internal leakage is listed at 1.1 to 1.52 in³/min at 2285 PSI.

Question by: Chad P on Apr 12, 2025, 11:46 AM

Can this handle hydraulic oil with a viscosity kinda thick, like up to 400 cSt?

Answer by: Customer Support on Apr 14, 2025, 6:56 AM

This Salami VD6A series valve section works best with hydraulic fluid that's between 12 cSt and 75 cSt. While it *can* handle up to 400 cSt, you'll get the most efficient performance staying within that recommended range. Going too thick might slow things down a bit.
