VD8A Series SALAMI VD8A/U4S

Description & Features

Manufactured by Salami S.p.A, this valve outlet showcases a maximum operating pressure of 5100 PSI on ports "P", "A", and "B".

Featuring a robust flow rating of 20 GPM, it supports fluid temperatures ranging from -4deg;F to 185deg;F with standard NBR seals. Its internal leakage rate ranges from 1.52 to 2.13 insup3;/min. at 2285 PSI.

The product ensures optimal fluid viscosity from 12 cSt to 75 cSt, while maintaining a maximum back pressure of 363 PSI on outlet port T.

Designed to function within an ambient temperature range of 86deg;F to 140deg;F, recommended filtration is ISO 4406: 19/16 to maintain performance.

Note that all technical data was determined using mineral oil with a viscosity of 16 cSt and contamination level 19/16 according to ISO 4406 standards.

Supplier Part Number: R23580030

Specifications

Brand Salami	Product Type Outlet Section	Sg Fluid Viscosity 12 cSt to 75 cSt Optimal, 10 cSt Minimum, 400 cSt Maximum	Sg Internal Leakage 1.52 to 2.13 cu-in/min at 2285 psi	Sg Maximum Back Pressure 363 psi on Outlet Port T	Sg Recommended Filtration 19/16 um	Suitable For Use With VD8A/U4S Series Hydraulic Proportional (IP) Control Directional Valves

Similar Products

Model Number	Product Description	Price	Action
R23580020 VD8A Series Valve Outlet	SALAMI VD8A/POWER BEYOND SLEEVE

Product Questions & Answers (4)

Question by: Ray W on Aug 25, 2025, 5:35 PM

got a system that runs close to 5,000 psi, is this VD8A/U4S ok on the work ports?

Answer by: Customer Support on Aug 26, 2025, 6:32 PM

On ports P, A, and B the maximum operating pressure is rated at 5100 PSI, so it is intended to handle systems running up near 5,000 PSI on those ports.

Question by: Sherry P on Aug 13, 2025, 6:41 AM

what's the highest pressure this valve outlet can handle on the work ports?

Answer by: Customer Support on Aug 14, 2025, 12:36 PM

Ports P, A, and B are all rated to 5100 PSI maximum operating pressure. Port T on the outlet side has a much lower ceiling at 363 PSI back pressure, so that one needs to stay well within range. The specs were validated using mineral oil at 16 cSt viscosity, so keep that in mind when comparing to your system conditions.

Question by: Sheila W on Nov 5, 2025, 10:59 AM

What kind of fluid should I be running in this thing?

Answer by: Customer Support on Nov 7, 2025, 6:49 AM

Optimal fluid viscosity for the VD8A Series valve outlet is between 12 cSt and 75 cSt, but it can handle mineral oil with a viscosity of 16 cSt.

Question by: Bobby A on Apr 19, 2025, 7:27 AM

got a VD8A setup and need an outlet section, is this the VD8A/U4S one and what’s the part number?

Answer by: Customer Support on Apr 21, 2025, 6:24 AM

For replacement matching, the identifier to go by is the supplier part number R23580030 and the model callout VD8A/U4S in the Salami VD8A Series outlet section.
