Salami VDM8/VD8 02A M Spool

Description & Features

Manufactured by Salami S.p.A the Salami VD8A Series spool valve delivers exceptional performance in demanding environments. Operating efficiently within an ambient temperature range of 86deg;F to 140deg;F it supports fluid temperatures from -4deg;F to 185deg;F with standard NBR seals and maintains optimal fluid viscosity between 12 cSt to 75 cSt. This spool valve demonstrates internal leakage rates of 1.52 - 2.13 insup3;/min. at 2285 PSI.

Designed for high-pressure scenarios it operates at maximum pressures of 5100 PSI on ports "P" "A" and "B" and 363 PSI on outlet port T. Featuring a flow rating of 20 GPM the component ensures reliable and efficient fluid control. Adhering to ISO 4406 filtration standards with a contamination level of 19/16 it is highly suited for industrial applications requiring rigorous standards.

Catalog Number: C1MQ75

Supplier Part Number: 323511302

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key Spool	Supplier Part Number 323511302	Alternate Part Numbers Alternate Part Number C1MQ75	Product Weight 0.94 lbs

Similar Products

Model Number	Key	Product Description
323511302 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A M SPOOL.
420290180 VD8A Series Working Section	A side actuator	SALAMI HANDLEVER. VALVE HANDLE. SHAFT/KN.
796366200 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 VA SETTING (20 TO 70 BA.
796366700 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 PORT RELIEF AR (0-420 B.
R23500300 VD8A Series Working Section	B	SALAMI R2 DETENT KIT
R23573049 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A ELECTRIC KIT ESA WIT.

Product Questions & Answers (3)

Question by: Neil M on Dec 12, 2025, 8:35 AM

what's the max pressure this spool can handle on the work ports?

Answer by: Customer Support on Dec 14, 2025, 6:02 AM

Ports P, A, and B are all rated to 5100 PSI. The outlet port T runs a much lower limit at 363 PSI, so that backpressure ceiling is worth keeping in mind when you're hydraulic connections the return line. Flow rating on this valve is 20 GPM, and internal leakage at 2285 PSI falls in the 1.52 to 2.13 cubic inches per minute range.

Question by: Lance T on Dec 12, 2025, 8:46 AM

What kind of fluid should I be using in this valve? Gotta make sure I don't muck anything up.

Answer by: Customer Support on Dec 13, 2025, 8:49 AM

Optimal performance is achieved using fluid with a viscosity between 12 cSt and 75 cSt. The valve can handle fluid temps from -4°F to 185°F when using standard NBR seals.

Question by: Rod M on Aug 15, 2025, 7:01 PM

got a hydraulic setup that sees about 20 gpm. is this spool gonna be a choke point or is it sized for that

Answer by: Customer Support on Aug 17, 2025, 8:12 AM

For flow, it is rated at 20 GPM, so it is sized to handle that rate as its published capacity.
