Salami HAndLEVER. Valve HAndLE. Shaft/KN

Description & Features

Optimize fluid control with this precise Salami HAndLEVER. Valve HAndLE. Shaft/KN from Salami Hydraulics NA Inc. Engineered for efficiency this actuator supports maximum operating pressures of 5100 PSI on ports "P" "A" and "B".

Maintaining performance at fluid temperatures from -4deg;F to 185deg;F with standard NBR seals the actuator ensures reliable operations across diverse conditions. It supports a flow rating of 20 GPM making it suitable for high-demand sectional applications.

Internal leakage is minimal ranging between 1.52 - 2.13 insup3;/min. at 2285 PSI ensuring consistent fluid control. Optimal fluid viscosity ranges from 12 cSt to 75 cSt with operational limits from 10 cSt to 400 cSt.

Recommended filtration standard is ISO 4406: 19/16 ensuring longevity and cleanliness. The maximum back pressure on the outlet port T is maintained at 363 PSI. Ambient temperature performance ranges from 86deg;F to 140deg;F providing versatile utility in various environments.

MPN: C1MQ95

Supplier Part Number: 420290180

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key A side actuator	Supplier Part Number 420290180	Alternate Part Numbers Alternate Part Number C1MQ95, Alternate Part Number MI-02129695, Alternate Part Number MINO-00770X10805	Product Weight 0.13 lbs

Similar Products

Model Number	Key	Product Description
323511302 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A M SPOOL.
420290180 VD8A Series Working Section	A side actuator	SALAMI HANDLEVER. VALVE HANDLE. SHAFT/KN.
796366200 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 VA SETTING (20 TO 70 BA.
796366700 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 PORT RELIEF AR (0-420 B.
R23500300 VD8A Series Working Section	B	SALAMI R2 DETENT KIT
R23573049 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A ELECTRIC KIT ESA WIT.

Product Questions & Answers (2)

Question by: Cindy P on Oct 8, 2025, 5:02 PM

got a VD8A working section, i just need the side actuator handlelever deal. is this the right one?

Answer by: Customer Support on Oct 9, 2025, 7:31 PM

For a VD8A Series working section, this part is the A side actuator handle lever assembly listed as a valve handle with shaft/knob, catalog number C1MQ95 (supplier part 420290180).

Question by: Sheila B on Mar 25, 2026, 9:43 AM

what's the max pressure this handlever setup can handle on the work ports?

Answer by: Customer Support on Mar 26, 2026, 6:12 PM

Ports P, A, and B are all rated to 5100 PSI. Back pressure on the outlet port T tops out at 363 PSI, so keep that in mind when you're routing your return line. Flow rating comes in at 20 GPM, which puts it in solid territory for sectional valve work.
