Salami VDM8/VD8 NP Global LEVER ( M8

Description & Features

This Salami VDM8/VD8 NP Global LEVER ( M8 is a working section valve from the Salami VD8A series, designed for optimal performance in demanding hydraulic applications. It maintains stable operation across a fluid viscosity range of 12 cSt to 75 cSt, with a minimum of 10 cSt and a maximum of 400 cSt. The valve is engineered to withstand a maximum operating pressure of 5100 PSI on ports "P", "A", and "B".

This hydraulic lever section ensures reliable functionality with a flow rating of 20 GPM. Its design provides consistent performance within a fluid temperature range of -4°F to 185°F when using standard NBR seals. It is designed to handle a maximum back pressure of 363 PSI on outlet port T.

SKU: R20287910

Supplier Part Number (MPN): R20287910

Alternate Part Numbers: C1MT44

Specifications

Brand Salami	Key B side actuator	Sg Fluid Viscosity 12 cSt to 75 cSt Optimal, 10 cSt Minimum, 400 cSt Maximum	Sg Internal Leakage 1.52 to 2.13 cu-in/min at 2285 psi	Sg Maximum Back Pressure 363 psi on Outlet Port T	Sg Recommended Filtration 19/16 um	Suitable For Use With VD8A Series Control Directional Valves and VDM8 Series Monoblock Directional Valves

Product Questions & Answers (1)

Question by: Johnny W on Mar 27, 2026, 6:47 AM

Hey, can this handle a good amount of pressure? My setup can get pretty intense.

Answer by: Customer Support on Mar 29, 2026, 6:07 AM

It is rated to handle a maximum operating pressure of 5100 PSI on ports "P", "A", and "B", so it should be able to withstand quite a bit.
