Salami R2 Detent Kit

Description & Features

Designed for use with the Salami VD8A Series working section, the Salami R2 Detent Kit provides the mechanical detent function needed to hold spool positions without continuous operator input. It is cataloged under part number C1MU35 and fits within the VD8A Series directional control valve platform.

The VD8A Series is rated to 5100 PSI on work and pressure ports, with a flow rating of 20 GPM. Fluid temperature tolerance ranges from -4°F to 185°F with standard NBR seals, and the system is optimized for fluid viscosity between 12 cSt and 75 cSt. Recommended filtration is ISO 4406: 19/16, consistent with mineral oil service at 16 cSt.

This kit is a direct replacement or configuration component for Salami VD8A assemblies requiring detent-style spool control in mobile or industrial hydraulic circuits.

SKU: R23500300

Supplier Part Number (MPN): R23500300

Alternate Part Numbers: C1MU35

Specifications

Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Key B	Supplier Part Number R23500300	Alternate Part Numbers Alternate Part Number C1MU35	Product Weight 0.55 lbs

Similar Products

Model Number	Key	Product Description
323511302 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A M SPOOL.
420290180 VD8A Series Working Section	A side actuator	SALAMI HANDLEVER. VALVE HANDLE. SHAFT/KN.
796366200 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 VA SETTING (20 TO 70 BA.
796366700 VD8A Series Working Section	Main relief	SALAMI VD8A/VDM8 PORT RELIEF AR (0-420 B.
R23500300 VD8A Series Working Section	B	SALAMI R2 DETENT KIT
R23573049 VD8A Series Working Section	Spool	SALAMI VDM8/VD8 02A ELECTRIC KIT ESA WIT.

Product Questions & Answers (3)

Question by: Wes H on Apr 10, 2025, 6:53 PM

Does this detent kit work with all VD8A working sections, or just certain builds?

Answer by: Customer Support on Apr 12, 2025, 6:20 PM

It fits within the VD8A Series directional control valve platform specifically. The R2 Detent Kit is built to add mechanical detent function to VD8A working sections, so the spool holds its position without the operator keeping pressure on the handle. If your valve assembly is VD8A Series, this is the correct detent configuration component for that platform.

Question by: Rod H on Aug 18, 2025, 2:23 PM

If I'm usin' this detent kit, what kinda pressure can the valve handle? Don't wanna blow nothin' up.

Answer by: Customer Support on Aug 20, 2025, 6:27 AM

This kit works with the Salami VD8A series, which is rated up to 5100 PSI on the main ports.

Question by: Stan R on Oct 23, 2025, 4:13 PM

got a VD8A working section that won’t stay put unless you keep your hand on it. is this the little detent kit that holds the spool position

Answer by: Customer Support on Oct 25, 2025, 8:40 AM

Mechanical detent is exactly what the R2 kit adds. It is meant for the Salami VD8A Series working section so the spool can stay in the selected position without constant operator input.
