Dentent Positioning Kit (R4), Detent on position 1 with spring return in neutral.

The Dentent Positioning Kit (R4) is designed for precise hydraulic control, featuring a detent on position 1 with a spring return to neutral. Ideal for applications requiring reliable positioning, this kit is part of the Salami VD8A Series, known for its robust performance. It operates efficiently within an ambient temperature range of 86°F to 140°F and accommodates a flow rate of up to 20 GPM. Engineered to withstand a maximum operating pressure of 5100 PSI on ports "P", "A", and "B", this kit is built to handle demanding environments. Optimal fluid viscosity ranges from 12 cSt to 75 cSt, ensuring smooth operation and longevity.

For optimal performance, it is recommended to maintain a fluid temperature range between -4°F and 185°F, supported by standard NBR seals. The maximum back pressure is set at 363 PSI on outlet port T, while the internal leakage is maintained between 1.52 - 2.13 in³/min at 2285 PSI, ensuring minimal power loss and efficient operation.

SKU: R23500400

Alternate Part Numbers: C1MU36
