SALAMI PP PNEUMATIC PROPORTIONAL KIT

Designed for the Salami VD8A Series, this pneumatic proportional kit supports B-side actuator control and is built to handle demanding hydraulic circuit conditions. It carries a maximum operating pressure of 5,100 PSI on ports P, A, and B, with a maximum back pressure of 363 PSI on the outlet port T. The SALAMI PP Pneumatic Proportional Kit has a flow rating of 20 GPM and is compatible with fluid viscosities ranging from 10 cSt minimum to 400 cSt maximum, with an optimal working range of 12 to 75 cSt.

Fluid temperature tolerance spans -4°F to 185°F using standard NBR seals, and the kit is rated for ambient temperatures between 86°F and 140°F. Internal leakage is rated at 1.52 to 2.13 in³/min. at 2,285 PSI. Recommended filtration is ISO 4406: 19/16. All technical data is based on mineral oil at 16 cSt viscosity and a contamination level of 19/16 per ISO 4406.

SKU: R23575370

Supplier Part Number (MPN): R23575370

Alternate Part Numbers: C1MU44
