Cross Lever for 2 spools (L2) fulcrum on up-stream spool

Description & Features

Designed for precision and reliability, the Salami VD8A Series Cross Lever is optimized for two spools (L2) with a fulcrum on the upstream spool. This component is engineered to handle a maximum operating pressure of 5100 PSI on ports "P", "A", and "B", ensuring robust performance in demanding hydraulic systems. It accommodates a flow rating of 20 GPM, making it suitable for various industrial applications.

The working section's ambient temperature range spans from 86°F to 140°F, while it operates efficiently with fluid temperatures between -4°F and 185°F, thanks to standard NBR seals. It is compatible with mineral oils having a viscosity from 12 cSt up to 75 cSt for optimal performance, but can handle viscosities from 10 cSt to 400 cSt. Designed with minimal internal leakage of 1.52 - 2.13 in³/min at 2285 PSI, it maintains system efficiency under high pressure.

SKU: R23587580

Supplier Part Number (MPN): R23587580

Alternate Part Numbers: C1MU64

Specifications

Brand Salami S.P.A	Brand Salami S.P.A	Pack Size 1.00	UOM EA	Key B side actuator	Supplier Part Number R23587580	Alternate Part Numbers Alternate Part Number C1MU64	Product Weight 1.03 lbs

Product Questions & Answers (1)

Question by: Glen F on Apr 28, 2025, 4:04 PM

Reckon this lever setup can handle the pressure on my system? I'm pushin' close to the max sometimes.

Answer by: Customer Support on Apr 30, 2025, 6:21 AM

This Salami VD8A series cross lever is built to withstand up to 5100 PSI on ports "P", "A", and "B". Make sure your system isn't exceeding that to keep everything running smoothly.
