Port relief and anti-cavitation valve (AR) kit, non-adjustable, 3000 PSI. Includes plug, seal and fixed setting valve (794129313).

Designed for robust hydraulic systems, the Port relief and anti-cavitation valve (AR) kit offers non-adjustable settings with a pressure rating of 3000 PSI. This kit, which includes a plug, seal, and fixed setting valve, ensures efficient pressure relief and anti-cavitation protection. It features a durable cast-iron monoblock construction and nickel-plated spools, providing high surface hardness and enhanced corrosion resistance. The valve operates within a temperature range of -22°F to 140°F, making it suitable for diverse industrial environments.

The valve is engineered with parallel circuits and load check valve protection, ensuring reliable operation under high-pressure conditions. It is compatible with mineral oil of 16 cSt viscosity and maintains an internal leakage rate of 1.52 to 2.13 in³/min at 2285 PSI. The valve supports a maximum operating pressure of 5100 PSI on ports "P", "A", & "B", and a back pressure limit of 363 PSI. Adhering to ISO 4406 standards, it recommends a filtration level of 19/16 to maintain optimal performance.

SKU: R23277620

Supplier Part Number (MPN): R23277620

Alternate Part Numbers: C1MT96
