Port load sense relief valve (LSVS) adjustable 1595 PSI to 5510 PSI

Designed for use within the Salami VDP08 Series load sensing directional control valve platform, this Port load sense relief valve (LSVS) adjustable 1595 PSI to 5510 PSI provides adjustable pressure control across a wide range to suit varying circuit demands. The load-sensing architecture delivers load-independent flow control, meaning flow through each working section is governed by spool position alone, not by the load acting on any given function. This supports consistent metering behavior and enables potential energy savings in multi-function hydraulic circuits.

Rated for flows up to 25 GPM, the valve accommodates fluid temperatures from -4°F to 185°F with standard NBR seals and performs within a fluid viscosity range of 10 to 460 cSt. Maximum operating pressure reaches 4560 PSI on the P port and 5000 PSI on the A and B ports, with a maximum back pressure of 145 PSI on the T outlet port. Recommended filtration is ISO 4406: 19/16, with all technical data referenced at 16 cSt viscosity and ISO 4406 contamination level 19/16.

SKU: R24170060

Supplier Part Number (MPN): R24170060

Alternate Part Numbers: C1MU66
