Port load sense relief valve (LSVS) adjustable 435 PSI to 1595 PSI

The Salami VDP08 Series port load sense relief valve is designed to offer adjustable pressure relief from 435 PSI to 1595 PSI, ensuring precise control in demanding hydraulic systems. This load-sensing directional control valve features load-independent flow control, where flow in each section is determined solely by the spool position, not the load. This results in improved energy efficiency and reliable performance across various applications.

With a flow rating of 25 GPM and a maximum operating pressure of 4560 PSI on port "P" and 5000 PSI on ports "A" and "B", this valve is suitable for high-pressure environments. It operates efficiently within a fluid temperature range of -4°F to 185°F and maintains optimal performance with fluid viscosities between 12 cSt to 75 cSt. The valve's construction ensures minimal internal leakage and supports a maximum back pressure of 145 PSI on the outlet port. Recommended filtration adheres to ISO 4406: 19/16 standards, enhancing reliability and longevity.

SKU: R24170061

Supplier Part Number (MPN): R24170061

Alternate Part Numbers: C1MU67
