LS port plug for single acting port B

This LS port plug is designed for use with the single acting port B on Salami VDP08 Series working sections. It is manufactured by Salami S.P.A and carries catalog number C1MU72.

This plug is designed to function in ambient temperatures from 86°F to 140°F, and fluid temperatures ranging from -4°F to 185°F when utilizing standard NBR seals. It has a flow rating of 25 GPM and is designed for use with a fluid viscosity of 12 cSt to 75 cSt, with 10 cSt minimum and 460 cSt maximum values. The maximum operating pressure is 4560 PSI on ports "P" and 5000 PSI on ports "A" and "B". The maximum back pressure is 145 PSI on outlet port "T".

SKU: R24172770

Supplier Part Number (MPN): R24172770

Alternate Part Numbers: C1MU72
