LS port plug for single acting port A

This LS port plug is designed for single acting port A applications within the Salami VDP08 Series of load sensing directional control valves. These valves provide load-independent flow control, ensuring flow in each section depends on the spool position rather than the load. The spool acts as a variable throttling point, maintaining constant pressure drop for consistent flow rates.

This plug is manufactured by Salami S.P.A. It is designed to operate within an ambient temperature range of 86°F to 140°F and a fluid temperature range of -4°F to 185°F when using standard NBR seals. The recommended filtration level is ISO 4406: 19/16. The maximum back pressure is 145 PSI on the outlet port "T", while the maximum operating pressure is 4560 PSI on ports "P" and 5000 PSI on ports "A" and "B".

SKU: R24172780

Supplier Part Number (MPN): R24172780

Alternate Part Numbers: C1MU73
