Work module, 11.8 GPM pressure compensated, manual control (NL), double acting cylinder spool, work port valves plugged (PRA.PRB), SAE -10 ports.

Description & Features

This Salami S.P.A VDP08 series work module features manual control (NL) and a double acting cylinder spool. The pressure compensated valve offers load-independent flow control, ensuring flow in each section depends on the spool position, not the load. It also provides good metering curves and energy saving potential.

With work port valves plugged (PRA.PRB) and SAE -10 ports, this work module has a maximum operating pressure of 4560 PSI on ports "P" and 5000 PSI on ports "A" and "B". It is designed for a fluid viscosity between 12 cSt and 75 cSt, and an ambient temperature range of 86°F to 140°F.

SKU: S24180100

Supplier Part Number (MPN): S24180100

Alternate Part Numbers: C1MW51

Specifications

Brand Salami S.P.A	Brand Salami S.P.A	Pack Size 1.00	UOM EA	Supplier Part Number S24180100	Alternate Part Numbers Alternate Part Number C1MW51	Product Weight 10.00 lbs

Product Questions & Answers (1)

Question by: Ross L on Aug 1, 2025, 1:45 PM

Reckon this'll work on my tractor's hydraulics? I'm running a double-acting cylinder setup.

Answer by: Customer Support on Aug 3, 2025, 9:32 AM

This work module's got a double-acting cylinder spool, so it should be compatible with your tractor's hydraulics, provided your system's within the pressure and flow specs.
