The Versa-Pak valve operates within a Dry Valve system by performing as a pressure compensated flow control ensuring a predetermined flow to the hydraulic system and redirecting excess flow to the tank at low pressure. This feature minimizes the risk of overspeeding and overpressurizing reducing both repairs and downtime.
Brand: Permco Inc.
Catalog Number: C1DR58
Model: Refuse Pump System
The dry valve system eliminates heat buildup associated with large flows when the system is idle. It is easily managed through a dash-mounted electric over air switch or manual air valve featuring a breather vent tubing and fittings for optimal function. The Permco Versa-Pak Pump with Dry Valve Fun for Refuse Pump System integrates a sealed outboard bearing with a protective shield to prevent contamination and uses dowel pin construction for superior reliability. Solid one-piece gear and shaft set ensure durability while a bleed valve built into the rear cover enhances efficiency.
MPN: P7600A467ZDNM22-00DVBP
Specifications
Alternate Part Numbers
Alternate Part NumberC1DR58, Alternate Part Number DSVP42-4COFLDV, Alternate Part Number MI-08752927, Alternate Part Number MINO-00653X76542, Alternate Part Number VP42-4CCFLDV
Brand
Permco Inc.
Brand
Permco
Pack Size
1.00
UOM
EA
Supplier Part Number
P7600A467ZDNM22-00DVBP
Product Weight
50.00 lbs
Similar Products
Model Number
Product Description
Price
Action
999-00948Versa-Pak Refuse Pump System
PERMCO VP SOLENIOD
VP42-4COFLDVVersa-Pak Refuse Pump System
PERMCO VERSA-PAK PUMP WITH DRY VALVE FUN
VP42-4COFLFC55Versa-Pak Refuse Pump System
PERMCO VERSA-PAK REFUSE PUMP
Product Questions & Answers (3)
Question by: Daryl H on Dec 24, 2025, 6:25 PM
What exactly does the dry valve do when the truck ain't running the hydraulic system, does it just sit there or is it actually doing something to protect things?
Answer by: Customer Support on Dec 26, 2025, 7:38 AM
When the system's idle, the dry valve keeps heat from building up by managing how flow gets handled. Without it, large flows circulating through an inactive system generate a lot of unnecessary heat. The Versa-Pak valve redirects excess flow back to the tank at low pressure instead of letting it churn through the system, so you're not cooking your fluid or stressing components while the operator's just waiting on the next stop. The operator kicks it on or off with either a dash-mounted electric over air switch or a manual air valve, so it's straightforward to manage day to day.
Question by: Harvey M on Sep 3, 2025, 8:27 AM
running a refuse truck, what’s the dry valve actually doing in this Versa-Pak setup?
Answer by: Customer Support on Sep 4, 2025, 10:01 AM
In a Dry Valve system, the Versa-Pak valve acts like a pressure compensated flow control. It sends a preset amount of flow to the hydraulic system, then routes the extra flow back to tank at low pressure. That helps prevent overspeeding and overpressurizing, and it also cuts down heat buildup when the system is sitting idle with big flow available.
Question by: Phil W on Jun 2, 2025, 1:05 PM
What kind of hydraulic system does this Versa-Pak pump work with?
Answer by: Customer Support on Jun 3, 2025, 2:04 PM
This Versa-Pak pump is designed for a refuse pump system that uses a dry valve.
