2 WING HD X 2 NPT F

Description & Features

A 2-inch wing-to-female NPT adapter from DNP Industriale Americas, the 2 WING HD X 2 NPT F is built for demanding hydraulic and industrial fluid connection applications. The heavy-duty wing configuration allows for tool-assisted tightening, providing a secure, leak-resistant joint suited to high-vibration or high-cycle service environments. Matching connection sizes at both ends supports full-bore flow paths where consistent throughput and connection integrity are required.

The female NPT thread on one end interfaces with standard threaded ports found across a wide range of industrial hydraulic equipment, while the wing design on the opposing end simplifies installation and removal in confined or frequently serviced assemblies. This fitting is well suited for use in hydraulic systems and industrial fluid transfer applications where a reliable mechanical connection between wing-style and NPT-threaded components is needed.

SKU: VFF-HD-32-32C

Supplier Part Number (MPN): VFF-HD-32-32C

Specifications

Brand dnp Americas	Connection Size 1 2 in	Connection Size 2 2 in	Connection Type NPT	Connection Type 1 NPT	Connection Type 2 NPT	Dimensions 4.71 in Dia x 6 in L	Finish Zinc Iron-Plated	Fitting Type Coupler	Hex Size 3-1/4 in	Material Carbon Steel/NBR	Material Construction Carbon Steel/NBR	Series VFF-HD Series

Product Questions & Answers (1)

Question by: Todd W on Sep 5, 2025, 9:43 AM

Will this fitting hold up to a good bit of vibration in a hydraulic system?

Answer by: Customer Support on Sep 6, 2025, 9:25 PM

Absolutely, this adapter is designed with a heavy-duty wing configuration specifically for secure joints in high-vibration environments. The tool-assisted tightening helps get it snug to prevent leaks, too.
