Water Suction & Discharge Hose, 2.50 Inch ID, Up To 150.00 PSI

Description & Features

This Hydraulic Supply Company water suction and discharge hose is designed for pumping, suction, and discharge of water, mud, and slurries. It is also suitable for conveying water and transferring saltwater (brine).

This black, 2.50-inch ID water suction & discharge hose features a synthetic rubber tube, textile and a single steel helical wire reinforcement, and an abrasion- and weather-resistant synthetic rubber cover. It has a maximum operating pressure of 150 PSI and a temperature range of -13°F to +158°F.

Suitable fittings include cam and groove and combination nipples with crimp, swage, or preformed clamps.

SKU: WATER-S&D-40

Supplier Part Number (MPN): EHW150-40-100

Alternate Part Numbers: C1MK52, EH36040-100

Specifications

Color Black	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 12.00	UOM FT	Hose I.D. 2.50	Hose O.D. 2.95	Maximum Operating Pressure 150	Minimum Bend Radius 11.02	Minimum Bend Radius 11.02	Package Qty. 100	Supplier Part Number EHW150-40-100	Vacuum Service 28	Alternate Part Numbers Alternate Part Number C1MK52, Alternate Part Number EH36040-100, Alternate Part Number MINO-00115X00277	Product Weight 0.44 lbs

Similar Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Burst Pressure	Minimum Bend Radius	Vacuum Service	Package Qty.
WATER-S&D-24 Water Suction & Discharge Hose	1.5	1.89	150		5.91	28	100
WATER-S&D-32 Water Suction & Discharge Hose	2	2.44	150		8.46	28	100
WATER-S&D-48 Water Suction & Discharge Hose	3	3.5	150	450	13.78	28	100
WATER-S&D-64 Water Suction & Discharge Hose	4	4	150		19.29	28	100
WATER-S&D-96 Water Suction & Discharge Hose	6	6.65	150		29.92	24	100
WATER-S&D-20 Water Suction & Discharge Hose	1.25	1.65	150		4.92	28	100
WATER-S&D-40 Water Suction & Discharge Hose	2.5	2.95	150		11.02	28	100

Product Questions & Answers (3)

Question by: Danny S on Dec 26, 2025, 8:36 AM

What kind of fittings work best with this hose, like if I'm hooking it up to a pump?

Answer by: Customer Support on Dec 27, 2025, 10:30 AM

Cam and groove fittings are a good choice, especially aluminum or polypropylene. Combination nipples also work well, and you'll want to use crimp, swage, or preformed clamps to attach them securely.

Question by: Roger W on Sep 14, 2025, 3:20 PM

got a 2-1/2 inch pump setup, will this hose handle suction without sucking flat on me

Answer by: Customer Support on Sep 16, 2025, 10:20 AM

For suction work, it’s built with a textile layer plus a single steel helical wire to help it hold its shape, and it’s rated for vacuum service up to 28.

Question by: Randy B on Feb 26, 2026, 9:15 AM

Got a pump setup moving slurry and muddy water off a job site, this 2.5 inch hose gonna hold up to that kind of use?

Answer by: Customer Support on Feb 28, 2026, 7:58 AM

Slurry and muddy water are exactly what this hose is built for. The tube is synthetic rubber, which holds up against abrasive material moving through it, and the cover is rated for both abrasion and weather resistance on the outside. You've got a single steel helical wire giving it structure so it won't collapse under suction. It handles up to 150 PSI and can pull 28 inches of vacuum, so it should pair up fine with most standard pump setups doing that kind of work.
