main product photo

Wildcat Hot Air Transfer Hose, 4.59 Inch OD, 4.00 Inch ID, Up To 100.00 PSI

Ask A Question

Description & Features

The Eaton Industrial Hose Wildcat hot air transfer hose is designed for material handling applications. This brown hose has an outside diameter of 4.59 inches and an inside diameter of 4.00 inches. It is rated for up to 100 PSI.

SKU: H034964-100

Supplier Part Number (MPN): H034964-100

Alternate Part Numbers: C1MS73, MI-08749686, MINO-00115X96542

Specifications

Brand
Boston® by Danfoss
Abrasion Resistance
Standard
Cover Material
EPDM
Dash Size
64
For Use With
Cam and Groove Hose Fittings
grp Construction
EPDM Tube, Textile with Dual Helical Wire Reinforcement, Pin-Pricked EPDM Cover
grp Fitting Attachment Suggestions
Cam and Groove, Combination Nipples
grp Fittings
Cam and Groove, Combination Nipples
Hose Color
Brown
Hose Type
Conductive, Hot
Lay Line Style
Ink Transfer
Nominal Size
#04
Package Form
Reel
Reinforcement
4-Ply Nylon Fabric and Steel Wire
Resistance Properties
Abrasion
Segment Code
B
Series
H0349 Series
Tube Material
EPDM

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
Wildcat Hot Air Transfer Hose, 3.56 Inch OD, 3.00 Inch ID, Up To 150.00 PSI

H034948-100 Wildcat Hot Air Transfer Hose

3

3.56

150

13.78

24

100

Product Questions & Answers (3)

Question by: Gary W on Mar 7, 2026, 11:56 AM
hose is rated to 300 degrees continuous or is that the peak before you start pushing it?
Answer by: Customer Support on Mar 8, 2026, 8:57 PM
Continuous operation runs up to 300°F. The 350°F rating is for intermittent exposure only, so if your process is running hot air at or near that upper number for extended stretches, you'd want to stay at or below the 300°F mark to keep the hose in good shape long term.
Question by: Todd P on Oct 8, 2025, 6:58 AM
What's the outside diameter on this Wildcat hose?
Answer by: Customer Support on Oct 10, 2025, 8:12 AM
This hose has an outside diameter of 4.59 inches.
Question by: Phil C on May 14, 2025, 9:36 PM
Got a hot air transfer application running around 95 PSI, this the right hose for that kind of setup?
Answer by: Customer Support on May 16, 2025, 1:34 PM
At 100 PSI max, you've got a little breathing room above your working pressure, which is generally where you want to be for consistent hot air transfer. The Wildcat is built for exactly that kind of material handling work, so the pressure range lines up fine for what you're describing.
